Mercury Muzzle Brake
$120.00 – $130.00
Description
MERCURY has been meticulously engineered to provide superior recoil reduction and neutralize muzzle rise with a smooth, balanced release of blast energy. Progressive 90º side ports vent combusting gases at intervals that spread out the recoil impulse for efficient, accurate follow-up shots. MERCURY is the choice for those seeking a compact, lightweight muzzle device with smooth recoil characteristics and Dynamount on-barrel sight compatibility. A timing nut is included for easy installation.
PROGRESSIVE 90 DEGREE PORTS
Ultra smooth recoil reduction and minimal shooter distraction.
100% CNC MACHINED IN THE USA
416 Stainless Steel with ultra-rugged salt bath nitride finish.
DYNAMOUNT READY
Barrel-mounted sight option eliminates sight deflection associated with handguard mounting.
Mercury .223 | 5.56 Technical Specs
- CALIBER
- Rated for the standard cartridges in the following calibers: 223 Rem, 5.56 x 45 NATO, 224 Valkyrie, 224 Weatherby Mag, 22-250 Rem, 222 Rem Mag, 222 Rem, 22 Nosler, 220 Swift, 22 PPC, 22 BR, 22 Hornet, 204 Ruger, 218 Bee
- MINIMUM BARREL LENGTH 12"
- BARREL THREAD 1/2-28 UNEF-2B
- BARREL THREAD LENGTH MINIMUM .600"
- MATERIAL
- 416 Stainless Steel
- Salt Bath Nitride Finish
- MOUNTING Shrouded Timing Nut
- MASS
- Brake Only 87 grams | 3.1 ounces
- Total 110 grams | 3.9 ounces
- DIMENSIONS
- Length 62 mm | 2.43 inches
- OD 22 mm | 0.865 inches
- WRENCH FLATS 3/4 inch
- TIMING NUT WRENCH FLATS 13/16 inch
- CALIBER
- Rated for the standard cartridges in the following calibers: 6.5 PRC, 264 Win Mag, 6.5 Rem Mag, 260 Rem, 26 Nosler, 6.5-284 Norma, 6.5×47 Lapua, 6.5×55 Swedish, 6.5×52 Carcano, 6.5×57 Mauser, 6.5 Creedmoor, 6.5 Grendel, 6mm Remington, 6mm Rem, 6mm BR, 25-06 Rem, 257 Weatherby Mag, 257 Roberts, 243 WSSM
- MINIMUM BARREL LENGTH 12″
- BARREL THREAD 5/8-24 UNEF-2B
- BARREL THREAD LENGTH MINIMUM .600″
- MATERIAL
- 416 Stainless Steel
- Salt Bath Nitride Finish
- MOUNTING Shrouded Timing Nut
- MASS
- Brake Only 117 grams | 4.2 ounces
- Total 145 grams | 5.2 ounces
- DIMENSIONS
- Length 69.85 mm | 2.75 inches
- OD 24.77 mm | .975 inches
- WRENCH FLATS 7/8 inch
- TIMING NUT WRENCH FLATS 15/16 inch
- CALIBER
- Rated for the standard cartridges in the following calibers: 300 Win Mag, 300 PRC, 300 Weatherby mag, 300 WSM, 30 Nosler, 308 Norma Magnum, 308 Win, 7.62×51 NATO, 30-06 Springfield, 300 AAC Black Out, 300 Savage, 303 Savage, 30-30 Win, 7mm Rem Mag, 7mm Rem Ultra Mag, 7mm Weatherby Mag, 7mm WSM, 7mm-08 Rem, 7mm BR, 7×57 Mauser, 284 Win, 280 Rem, 28 Nosler, 270 Weatherby Mag, 270 WSM, 270 Win, 6.8mm Rem SPC
- MINIMUM BARREL LENGTH 12″
- BARREL THREAD 5/8-24 UNEF-2B
- BARREL THREAD LENGTH MINIMUM .600″
- MATERIAL
- 416 Stainless Steel
- Salt Bath Nitride Finish
- MOUNTING Shrouded Timing Nut
- MASS
- Brake Only 115 grams | 4.1 ounces
- Total 143 grams | 5.1 ounces
- DIMENSIONS
- Length 69.85 mm | 2.75 inches
- OD 24.77 mm | .975 inches
- WRENCH FLATS 7/8 inch
- TIMING NUT WRENCH FLATS 15/16 inch
Jeffrey –
Typical brake as far a noise and gas, but it far surpassed my expectations in recoil reduction. IMO the recoil is less than shooting a .22. I’m absolutely loving it!
Brian Thompson (verified owner) –
I mounted a Ultradyne Mercury muzzlebrake to a Savage 110 VSX chambered in .300 Win mag. The rifle weighs 8.7 pounds and has a 24 inch fluted barrel. In my opinion it is a very lightweight rifle and kicks like a mule. But after the addition of the Mercury brake it has recoil comparable to my wife’s Ruger M77 chambered in 243. It is absolutely unbelievable!!!
