Apollo Max

(26 customer reviews)

$149.00$159.00

SKU: N/A Category:

Description



APOLLO MAX sets the standard for performance by providing breakthrough recoil reduction and unparalleled muzzle compensation for those who refuse to settle for second best. Utilizing advanced imaging and precision instrumentation, Ultradyne engineers have created an ultra-high performance, competition level compensator. Gases are strategically diverted away from the shooter and out of the shooters line of sight. Experience smooth, on-target recoil compensation in a competition-legal package.  A timing nut is included for easy installation.

ULTIMATE RECOIL REDUCTION
Class-leading performance.
100% CNC MACHINED IN THE USA
416 Stainless Steel with ultra-rugged salt bath nitride finish.
DYNAMOUNT READY
Barrel mounted sight option eliminates sight deflection associated with handguard mounting.

Apollo Max 223 | 5.56 Technical Specs

  • CALIBER
    • Rated for the standard cartridges in the following calibers: 223 Rem, 5.56 x 45 NATO, 224 Valkyrie, 224 Weatherby Mag, 22-250 Rem, 222 Rem Mag, 222 Rem, 22 Nosler, 220 Swift, 22 PPC, 22 BR, 22 Hornet, 204 Ruger, 218 Bee
  • MINIMUM BARREL LENGTH   16″
  • BARREL THREAD  1/2-28 UNEF-2B
  • BARREL THREAD LENGTH MINIMUM    .600″
  • MATERIAL
    • 416 Stainless Steel
    • Salt Bath Nitride Finish
  • MOUNTING Shrouded Timing Nut
  • MASS
    • Brake Only 124 grams | 4.4 ounces
    • Total 147 grams | 5.2 ounces
  • DIMENSIONS
    • Length 75mm | 2.94 inches
    • OD 24.8 mm | 0.975 inches
  • WRENCH FLATS 7/8 inch
  • TIMING NUT WRENCH FLATS 13/16 inch

Apollo Max 264 | 6.5 Technical Specs

  • CALIBER
    • Rated for the standard cartridges in the following calibers: 6.5 Creedmoor, 6.5 Grendel, 6mm Remington, 6mm Rem, 6mm BR, 6mm ARC, 25-06 Rem, 257 Roberts, 243 WSSM
    • NOT COMPATIBLE WITH 6.5 PRC, PLEASE SEE APOLLO LR 6.5
  • MINIMUM BARREL LENGTH   16″
  • BARREL THREAD 5/8-24 UNEF-2B
  • BARREL THREAD LENGTH MINIMUM    .600″
  • MATERIAL
    • 416 Stainless Steel
    • Salt Bath Nitride Finish
  • MOUNTING Shrouded Timing Nut
  • MASS
    • Brake Only 130 grams | 4.5 ounces
    • Total 156 grams | 5.4 ounces
  • DIMENSIONS
    • Length 75mm | 2.94 inches
    • OD 24.8 mm | 0.975 inches
  • WRENCH FLATS 7/8 inch
  • TIMING NUT WRENCH FLATS 15/16 inch

Apollo Max 308 | 7.62 Technical Specs

  • CALIBER
    • Rated for the standard cartridges in the following calibers: 308 Win, 7.62×51 NATO, 7.62×39, 300 AAC Black Out, 300 Savage, 303 Savage, 30-30 Win
    • NOT COMPATIBLE WITH 7MM, 7MM PRC, PLEASE SEE APOLLO LR 7MM
    • NOT COMPATIBLE WITH 300 WIN, 300 PRC, 30-06 Springfield, PLEASE SEE APOLLO LR 300
  • MINIMUM BARREL LENGTH   16″
  • BARREL THREAD 5/8-24 UNEF-2B
  • BARREL THREAD LENGTH MINIMUM    .600″
  • MATERIAL
    • 416 Stainless Steel
    • Salt Bath Nitride Finish
  • MOUNTING Shrouded Timing Nut
  • MASS
    • Brake Only 130 grams | 4.5 ounces
    • Total 156 grams | 5.4 ounces
  • DIMENSIONS
    • Length 75mm | 2.94 inches
    • OD 24.8 mm | 0.975 inches
  • WRENCH FLATS 7/8 inch
  • TIMING NUT WRENCH FLATS 15/16 inch

Muzzle Device Knowledge

Muzzle Devices offer numerous benefits to the shooter including allowing for more accuracy and quicker follow up shots.   Reducing Recoil is often the primary goal and while low recoil reduces muzzle rise it does not totally eliminate it.   A well-designed Muzzle Device will incorporate features to address Muzzle Rise as well.   Reduced Recoil and Muzzle Rise are both accomplished by redirecting expanding gases.   It is important for the shooter to understand that redirecting gas has consequences.   Redirected gas away from the bullet path helps accuracy and speed for the shooter but also creates more sound, concussion, and unburnt gas particles to contend with.   It is vital that the shooter understand the Redirected Gas Path (RGP) for the Muzzle Device they choose.



RGP direction and volume are determined by the Muzzle Device ports.    The more gas volume that is redirected the higher the performance of the Muzzle Device.   Many high performance Muzzle Devices can turn gas at an extreme angle rearward and the shooter must be comfortable that body parts are positioned on the firearm so not to be negatively impacted.   It is important to understand that RGP is not accurately definable as different ammunition using the exact same firearm/Muzzle Device combination will vary.   Atmospheric pressure, temperature and elevation also effect powder burn and expanding gas effects in the RGP.



Ultradyne offers different Muzzle Devices that redirect gases at varying angles to provide a muzzle device option for every shooter.  With this being said, it is important for the shooter to understand their proximity to the Muzzle Device itself and determine if the RGP will cause problems.   For example, the RGP on a traditional M4 16” barrel with a combat forearm equipped with an Apollo Max will bypass a 5’9” shooter totally, however the RGP on a gun that is equipped with a fully extended hand guard and 20” barrel could possibly impact the arm of a 6’6” shooter that uses a fully extended arm style grip.   It is truly up to the shooter to determine the ideal set up for an acceptable Redirected Gas Path (RGP) for the ammo, firearm and individual shooting style to be used.
