ATHENA is Ultradyne’s linear compensator. Muzzle rise has been optimized, with gas vented at an angle then forward. This sends a lower percent of sound and gasses back towards the shooter, optimizing sonic performance over recoil. Athena gives a cleaner appearance for a sleek look compared to traditional brakes and is the most cost-effective way to upgrade a rifle to the Dynamount Sighting System. Like all Ultradyne muzzle devices, a timing nut is included for easy installation ( Crush washer for the .350 caliber). Available in the following; .223  / 5.56, .308 / 7.62 and 350 Legend.

  • Vents Gases forward
  • Timing nut included for easy installation and indexing
  • Indexing slots compatible with the Dynamount Front Sight allow for a standard upright alignment or a 45 degree offset
  • 100% CNC-machined quality
  • 100% Made in the USA

Forward-directed signature for greater shooter comfort.

416 Stainless Steel with ultra-rugged salt bath nitride finish.

Barrel mounted sight option eliminates sight deflection associated with handguard mounting.

Athena .223 | 5.56 Technical Specs

    • Rated for the standard cartridges in the following calibers: 223 Rem, 5.56 x 45 NATO, 224 Valkyrie, 224 Weatherby Mag, 22-250 Rem, 222 Rem Mag, 222 Rem, 22 Nozler, 220 Swift, 22 PPC, 22 BR, 22 Hornet, 204 Ruger, 218 Bee
    • 416 Stainless Steel
    • Salt Bath Nitride Finish
  • MOUNTING Shrouded Timing Nut
  • MASS
    • Brake Only 109 grams | 3.8 ounces
    • Total 133 grams | 4.7 ounces
    • Length 43mm | 1.69 inches
    • OD 24.8 mm | 0.975 inches
  • WRENCH FLATS 7/8 inch

Athena .308 | 7.62 Technical Specs

    • Rated for the standard cartridges in the following calibers: 308 Win, 7.62x51 NATO, 300 AAC Black Out, 300 Savage, 303 Savage, 30-30 Win
    • 416 Stainless Steel
    • Salt Bath Nitride Finish
  • MOUNTING Shrouded Timing Nut
  • MASS
    • Brake Only 130 grams | 4.6 ounces
    • Total 158 grams | 5.56 ounces
    • Length 43mm | 1.70 inches
    • OD 27.9 mm | 1.10 inches
  • WRENCH FLATS 1 inch

Athena 350 Legend Technical Specs *1/2-28 UNEF-2b*

    • Rated for the 350 Legend
  • BARREL THREAD 1/2-28 UNEF-2B AND 5/8-24 UNEF-2B
    • 416 Stainless Steel
    • Salt Bath Nitride Finish
  • MOUNTING *Crush Washer*
  • MASS
    • Brake Only 114 grams | 4.0 ounces
    • Total 122 grams | 4.1 ounces
    • Length 51mm | 2 inches
    • OD 27.9 mm | 1.10 inches
  • WRENCH FLATS 1 inch
    • 1/2 -28 Variation: 1/2 inch
    • 5/8 -24 Variation: 5/8 inch
  • Installation Instructions For Crush Washer:

    1. Inspect and clean threads on barrel and muzzle device.
    2. Place the crush washer cone forward over the muzzle threads, then thread the muzzle device up against the crush washer.
    3. Hand tighten the muzzle device and note that crush must be flush with barrel shoulder and fully depress the detent.
    4. Using a wrench, turn the muzzle device 1/4 turn, then continue to tighten to index properly. If the muzzle device is tightened past desired position, start over with a new crush washer.
    5. Check concentricity with a bore alignment rod.
    6. Test fire at 25 yards into a paper target backed up by a minimum 15' x 15' safety berm capable of safely stopping projectiles. Verify the ability to shoot groups and inspect for baffle strikes for all loads that will be used.
