C4 Dynamount Folding Front Sight + Pegasus 6.5mm and .308

$219.00$349.00

Clear
SKU: N/A Categories: , , , ,

Description

Dynamount Information

Most of the time, shooters mount front sights on the picatinny rail of a free-float handguard.

By definition, a free-float handguard doesn’t move with the barrel. This means that when the handguard moves, the sights do too.

Even properly-installed handguards move, whether it’s from the weight of the firearm, a strong grip, or impact. Especially at the end, farthest from the point of attachment, and where most users mount sights.

A small amount of movement can make a big difference in point of aim. Movement as little as 0.01 inches at the handguard means almost 2 inches at 100 yards.

The solution is Dynamount. Barrel-mounted sights for consistent aim, every time.

The Dynalign sight picture provides more accurate and faster target acquisition, using a purely concentric sight picture that is similar to that used by Olympic target shooters.  Unlike red-dot or holographic sights, this sight picture does not obscure the target and actually enhances visibility due to the optical characteristics of apertures.

Most BUIS systems utilize a sight picture that is non-intuitive.  The brain’s visual systems are asked to align a circular rear aperture with a rectangular front post shape while simultaneously ignoring the “ears” that protect the front sight post.  Dynalign’s circle-within-circle sight picture allows for faster sight picture acquisition.  Additionally, the use of a front aperture further reduces parallax effect which makes accuracy less dependent on precise sight alignment.

The C4 DYNAMOUNT FRONT SIGHT is a high quality folding front sight that was engineered with accuracy in mind. Features include:

DYNALIGN SIGHT PICTURE TECHNOLOGY
Ultradyne exclusive alignment for accurate and immediate acquisition.

WINDAGE-ADJUSTABLE FOR ZEROING
Regain full range of rear windage adjustment and guarantee center-zero operation.

TOOL-LESS ELEVATION ADJUSTMENT
Make hassle-free adjustments anywhere, anytime.

INDEXABLE TO STANDARD UPRIGHT OR 45 DEGREES FOR OFFSET USE
Dynamount allows the user to install in either standard upright or offset configuration.

100% CNC MACHINED IN THE USA
American-made quality.

C4 Dynamount Folding Front Sight Technical Specs

  • Front Pin
    • Includes 12 MOA Dynalign aperture.
    • 8, 10, and 14 MOA Available
    • Standard Front Post Available
  • MOUNTING
    • Must mount with any Ultradyne Muzzle Device
  • WINDAGE (at 21″ Sight Radius)
    • 40 MOA Total
    • 1/2 MOA Per Click
  • ELEVATION (at 21″ Sight Radius)
    • 28 MOA Total
    • 1.25 MOA per 1/4 turn
  • MATERIAL
    • 4140 CrMo Steel, Salt Bath Nitride Finish
    • 7075 Aerospace Alloy, Hard Anodized
  • MASS 62g | 2.2oz

Pegasus Information

PEGASUS has been meticulously engineered to provide superior recoil reduction and neutralize muzzle rise with a smooth, balanced release of blast energy in a tanker-style compensator. Progressive 90º side ports vent combusting gases at intervals that spread out the recoil impulse for efficient, accurate follow-up shots. Like all Ultradyne muzzle devices, a timing nut is included for easy installation.  Rated for the following cartridges; 6.5 Creedmoor and .308 Win | 7.62 x 51.

100% CNC MACHINED IN THE USA

416 Stainless Steel with ultra-rugged salt bath nitride finish.
DYNAMOUNT READY
Barrel mounted sight option eliminates sight deflection associated with handguard mounting.

Pegasus 6.5 Technical Specs

  • CALIBER
    • Rated for the standard cartridges in the following calibers: 6.5 Creedmoor, 6.5 Grendal, 6.5 PRC, 264 Win Mag, 6.5 Rem Mag, 260 Rem, 26 Nosler, 6.5-284 Norma, 6.5×47 Lapua, 6.5×55 Swedish, 6.5×52 Carcano, 6.5×57 Mauser, 6mm Remington, 6mm Rem, 6mm BR, 25-06 Rem, 257 Weatherby Mag, 257 Roberts, 243 WSSM
  • BARREL THREAD 5/8×24 UNEF-2B
  • BARREL THREAD LENGTH MINIMUM    .600″
  • MATERIAL
    • 416 Stainless Steel
    • Salt Bath Nitride Finish
  • MOUNTING Shrouded Timing Nut
  • MASS
    • Brake Only 162 grams | 5.7 ounces
    • Total 189 grams | 6.7 ounces
  • DIMENSIONS
    • Length 62mm | 2.43 inches
    • OD 34.5 mm | 1.36 inches
  • WRENCH FLATS 1 inch

Pegasus 308 | 7.62 Technical Specs

  • CALIBER
    • Rated for the standard cartridges in the following calibers: 300 Win Mag, 300 PRC, 300 Weatherby mag, 300 WSM, 30 Nosler, 308 Norma Magnum, 308 Win, 7.62×51 NATO, 30-06 Springfield, 300 AAC Black Out, 300 Savage, 303 Savage, 30-30 Win, 7mm Rem Mag, 7mm Rem Ultra Mag, 7mm Weatherby Mag, 7mm WSM, 7mm-08 Rem, 7mm BR, 7×57 Mauser, 284 Win, 280 Rem, 28 Nosler, 270 Weatherby Mag, 270 WSM, 270 Win, 6.8mm Rem SPC
  • BARREL THREAD 5/8×24 UNEF-2B
  • BARREL THREAD LENGTH MINIMUM    .600″
  • MATERIAL
    • 416 Stainless Steel
    • Salt Bath Nitride Finish
  • MOUNTING Shrouded Timing Nut
  • MASS
    • Brake Only 162 grams | 5.7 ounces
    • Total 189 grams | 6.7 ounces
  • DIMENSIONS
    • Length 62mm | 2.43 inches
    • OD 34.5 mm | 1.36 inches
  • WRENCH FLATS 1 inch

Additional information

Weight .7 lbs
Dimensions 1.95 × 1.95 × 3.95 in
Cartridge

6.5 Creedmoor, .308 Win / 7.62 x 51

Add C4 Standard Rear Sight?

Yes, No

Add C4 Offset Rear Sight

Yes, No
